WBQ Piling Machines
for Precise Ground Screw Installation
Engineered Power
for Electric & Hydraulic Piling Systems
WBQ Piling Machines for Reliable Foundation Setup
WBQ offers a complete range of piling machines designed for accurate, stable, and efficient installation of screw foundations across solar and construction projects. Our portfolio includes Electric Pile Drivers, Hydraulic Piling Machines, and high-torque Hydraulic Power Heads, delivering consistent driving performance, excellent adaptability to various soil conditions, and dependable operation for professional foundation work.
Eco-Friendly Construction
No excavation or concrete required. Reduces costs, avoids environmental impact, and preserves natural terrain during installation.
Fast Installation
Screw-in method completes foundations in minutes, with no curing time needed, enabling immediate follow-up construction.
Significant Cost Savings
Total material and installation cost is roughly one-third that of concrete foundations, with additional savings by eliminating curing delays.
Reusable & Clean Removal
Reverse rotation enables easy extraction without damaging the site. Components are reusable for multiple projects, supporting sustainable construction.
All-Weather Operation
Operates reliably in rain, snow, and freezing conditions. No water required, maintaining high efficiency even in dry or water-scarce regions.
Adaptable to Challenging Sites
Ideal for swamps, slopes, waterways, narrow spaces, or pipeline zones where conventional methods are impractical or costly.
Piling Machine Series Comparison
Electric Pile Driver
Hydraulic Piling Machine
Hydraulic Power Head
| Model | Protection Type | Frequency (Hz) | Rated Voltage (V) | Rated Power (W) | Max. Torque (N·m) | Max. Speed (rpm) | Recommended Pile Size (mm) | Net Weight (kg) |
| WBQ HD-08 | Class II Double Insulation | 50-60 | AC 220 | 4600 | 6000 | 11 | Φ114 × 3000 | 22.9 |
| WBQ HD-06 | Class II Double Insulation | 50-60 | AC 220 | 2920 | 3200 | 20 | Φ76 × 2000 | 15.5 |
| WBQ HD-03 | Class II Double Insulation | 50–60 | AC 220 | 1500 | 1800 | 15 | Φ76 × 1200 | 9.2 |
| Model | Drilling Diameter (mm) | Drilling Depth (mm) | Engine Power (kW) | Operating Weight (kg) | Walk Speed (km/h) | Climbing Ability (°) | Overall Dimensions (mm) |
| WBQ MZ385Y-2 | 90-400 | 0–100000 | 84 | 5900 | 0–2.5 | 35 | 5300×1970×2635 |
| WBQ MZ130Y-2 | 90-300 | 0–100000 | 56 | 4710 | 0–2.5 | 35 | 4700×1950×2500 |
| WBQ MZ398Y | 90-400 | 0–100000 | - | 7300 | 0-2.5 | 45 | 4730×2110×2850 |
| WBQ 460Y-3 | - | 6000 | 84 | 7350 | 0-2.5 | 35 | 6240×2250×3000 |
| WBQ SWDL 150 | 76 | 1800 | 16 | 3000 | 4.7 / 2.6 | 20 | 5160×1400×2880 |
| WBQ SWDL 600 | 76–90 | 3000 | 54.9 | 7800 | 4.5 / 3.1 | 20 | 8437×2190×3150 |
| Model | Applicable Model (Tons) | Torque (N·m) | Flow (Lpm) | Max Drilling Diameter (Clay/Shale, mm) | Speed (Rpm) | Weight (kg) |
| WBQ WPD15000 | 10–15 | 5307–15967 | 80–170 | 900 | 23–48 | 192 |
| WBQ WPD20000 | 12–17 | 6715–20998 | 80–170 | 1000 | 15–32 | 200 |
| WBQ WPD6000 | 4.5–6 | 2570–6917 | 40–90 | 500 | 20–45 | 105 |
| WBQ WPD8000 | 5–7 | 3163–8786 | 50–100 | 600 | 20–40 | 106 |
| WBQ WPD9000 | 6–8 | 3854–9961 | 70–100 | 800 | 23–33 | 107 |
| WBQ WPD25000 | 15–22 | 8314–25768 | 80–170 | 1100 | 12–26 | 288 |
| WBQ WPD30000 | 17–25 | 15669–30393 | 80–170 | 1200 | 12–21 | 298 |
| WBQ WPD59000 | 20–35 | 27198–59403 | 100–250 | 1500 | 10–22 | 721 |
| WBQ WPD2500 | 1.5–3 | 790–2593 | 25–65 | 300 | 36–88 | 93 |
| WBQ WPD3000 | 2–4 | 1094–3195 | 25–70 | 300 | 30–82 | 94 |
| WBQ WPD3500 | 2.5–4.5 | 1374–3578 | 40–80 | 350 | 35–70 | 95 |
| WBQ WPD4000 | 3–5 | 1710–4117 | 40–80 | 350 | 30–60 | 96 |
application scenario
TECHNICAL SUPPORT
Construction Guidelines & System Integration Support
Construction Guidelines
We provide detailed guidance on soil evaluation, torque selection, installation depth, vertical alignment, and on-site safety standards. These instructions ensure reliable foundation performance across clay, sandy, gravel, wetland, and other complex terrains, enabling faster, consistent, and predictable project delivery.
System Integration Support
Our integration service guarantees full compatibility between WBQ hydraulic piling machines, electric pile drivers, power heads, and ground screw systems used in solar farms, fencing, greenhouse foundations, and light-steel structures. We provide standardized interface data, recommended pile configurations, and project-matched engineering parameters to help EPC teams select the optimal equipment setup.
